Thorne & Derrick are global distributors for the range of Abtech hazardous area products. This includes junction boxes, hazardous area and industrial enclosures and HV enclosures

T&D distribute the widest range of hazardous area products globally to many industries including oil and gas, petrochemical and offshore projects.

Pictured: Abtech Enclosures HV Enclosures

Abtech Enclosures Product Range

All Abtech enclosures are constructed from 316 grade stainless steel and come with IP66 rating as standard.

In addition to the above ratings, there is also great flexibility with regards to mounting and connection options.

Abtech enclosures can be tailored to specific needs resulting in over 50 possible combinations.

T&D are Global Distributors of Hazardous Area Equipment including ATEX, IECEx, INMETRO & GOST Certified products

Hazardous Area Electrical Equipment



Abtech Hazardous Area Enclosure Range
Enclosure Type Max Voltage (kV) Max Current (A) Max Conductor Size (mm2) Max Fault Rating (kA) Phase
Abtech LR Box 3.3 1250 1000 N/A 3
Abtech VPJB 3.3

1800

1000 N/A 3
Abtech MJB 8.3 Conductor Dependant 240 N/A 3 or 3 + N
Abtech DPJB 11 312 630 50 3 or 3 + N
Abtech HVJB 11 980 1000 45 3 or 3 + N
Abtech HVJB 125 11 980 1000 45 3 or 3 + N
Abtech BusBar Box 11 3000 1000 90 4 Busbars
Abtech SX125 11 312 630 50 3 or 3 + N
Abtech ABJB 15 980 1000 45 3 or 3 + N
Abtech TFJB 36 312 630 25 3
Abtech 4TJB 45 980 1000 35 3



Abtech Enclosures Hazardous Area Ratings
Enclosure Type Zone 1 Zone 2 (suitable for Class 1, Division 2) ATEX IECEx GOST-R
Abtech LR Box

Tick

Tick Tick
Abtech VPJB Tick Tick Tick
Abtech MJB Tick Tick Tick
Abtech DPJB Tick Tick; Tick
Abtech HVJB Tick Tick Tick Tick Tick

Abtech HVJB 125

Tick Tick Tick
Abtech BusBar Box Tick Tick Tick Tick
Abtech SX125 Tick Tick Tick
Abtech ABJB Tick Tick Tick
Abtech TFJB Tick Tick Tick
Abtech 4TJB Tick; Tick Tick
