Nexans Euromold 400TB Connectors Power Wind Turbines At Scottish Highlands Windfarm

By Chris Dodds on 9th December, 2014

Follow us on LinkedIn

Nexans Euromold 400TB Connectors Power Wind Turbines At Scottish Highlands Windfarm

Euromold 400TB Connectors.

T&D again demonstrate their ability to competitively supply HV 11kV cable Nexans Euromoldand accessory packages.







T&D have supplied 400m of 11kV Triplex BS7870 XLPE single core 70sqmm cable plus several sets of Nexans Euromold 400TB Elbow Connectors interface type C.

Nexans connectors are approved by UK DNO's for high voltage polymeric cable termination into gas insulated switchgear.

Type C Bushings - 400 Series Bushings M16 Bolted, Voltage Range 12-36kV, Current Rating 1250 Amps Copper Stud - Use Nexans 440TB Plug In Seperable Connector



  • Further reading

Nexans - High Voltage HV Test Rod Kits For Screened Separable Connectors

Specifying Nexans Euromold Connectors - MV Medium Voltage Bushing Interfaces A-F Explained
