Prysmian Click Fit 132kV EHV Cable Joints

By Chris Dodds on 13th August, 2015

Follow @ThorneanDerrick

Images Courtesy : David Young (HV Cable Jointer - Balfour Beatty Utilities)

Pictured : Prysmian 132kV Click Fit Cable Joint. Connector pressed on, semi-conductive screen glassed and groove cut in for shield.

T&D are distributors for Prysmian Cable Components which includes their range of Bicon cable joints, cable cleats, cable glands and jointer tooling for LV, MV and HV cables.

Pictured : Prysmian 132kV Click Fit Cable Joint. Groove cut in for shield.

Prysmian 132kV

• 132kV XLPE Cable 630mm² Cu/Pb
• 132kV XLPE Cable 1000mm² Cu/Pb
• Composite Outdoor Cable Terminations
• Single Core Transition Cable Joints
• Three Core Transition Cable Joints
• Link Boxes
• Bonding Lead



• CFJ-145 Click-Fit Straight Joint 138kV
• CFJX-145 Click-Fit Straight Joint With Sheath Interuptor 138kV
• CFJ-145-T Click-Fit Size Transition Joint 138kV
• CFJX-145-T Click-Fit Transition Joint With Sheath Interuptor 138kV
