High Voltage, High Specification Cable Duct Sealing For Network Rail Power Integrity

By Chris Dodds on 15th February, 2013

Follow @ThorneanDerrick

CSD RISE Cable Duct Sealing Systems

Fire, Gas, Watertight Sealing



CSD RISE Cable Duct Seals provide advanced protection to LV-HV power and S&T cables and equipment on Network Rail infrastructure. This includes protecting 25kV trackside high voltage power cables feeding into lineside substations on rail electricification schemes. 25kV single core power cables distribute HV power supplies from Network Rail track-side switching stations to the overhead line equipment on A.C. electrified lines.

Maintaining vital power supply and therefore revenue stream to the end client is not negotiable in the UK rail industry. Power outages caused by water ingress into substations can be prevented. CSD RISE can be used to seal vertical and horizontal cable ducts - the split insert sleeves grip to rail cables without sliding and falling out of the penetration.

CSD RISE cable duct seal systems are compatible with XLPE insulated high voltage power cables, this includes 11kV, 25kV and 33kV multi-core and single core cables. Furthermore, CSD RISE can seal and protect DNO specification 11kV Triplex cables on both public and private networks. More Info - HV Triplex Cable Duct Seals.

CSD RISE Duct Sealing System Benefits

• Cost-effective
• Up to four hours fire protection
• WIMES compliant
• Ensures DSEAR compliance
• High levels of water and gas tightness
• Ease of re-entry for adding cables
• Few components
• No frame required
• Suitable for Trefoil cables
• Age tested - 50 years
• Complies with ATEX regulations
• Resistant to Methane, Hydrogen Sulphide and Chlorine
• Resistant to submersion in Petrol and Diesel



Today's Low Price, Tomorrows High Cost

CSD is the market leading, advanced specification Cable Duct Sealing System with the project track record and intensive Test Reports.When specifying, installing and purchasing cable duct seals the actual material cost should always be contexted with the potential real cost of a product failure, in terms of time, reputation and money.

Under-specified cable duct sealing systems can leave you and your client in deep water.
