Cembre B35-45D Battery Crimping Tools

By Chris Dodds on 11th February, 2014

Follow @ThorneanDerrick

Cembre B35-45D Battery Crimping Tools

T&D are Main UK Distributors for the complete range of Cembre Crimping Tools.

• Hydraulic
• Battery
• Ratchet
• Mechanical

Cembre B35-45D Hydraulic Battery Crimp Tool


• Hydraulic Crimping Tool Dimensions (L x H x W) -  342mm x 108mm x 66mm
• Crimping Force of Cembre B35-45D Hydraulic Tool -  35kN
• Hydraulic Crimping Tool Rechargable Ni-MH Battery -  9.6V 2.0Ah
• Crimp Tool Weight (including Battery) - 2.1kg

Cembre B35-45D Hydraulic Battery Crimp Tool - Main Applications

• Crimping of LV Cable Lugs and Splices up to 150sqmm
• Crimping of "C" Sleeve (C-Tap) Cable Connectors up to 35sqmm
• Crimping of HV Cable Lugs and Splices up to 70sqmm

Cembre B35-45D Hydraulic Battery Crimping Tool - Features

• Hydraulic crimp tool head rotates 180° for operation in confined spaces
• Can be operated with one hand. Balanced for greater control
• Sculptured crimping tool body for optimum operator comfort
• Fitted with a maximum pressure valve
• Hydraulic crimp tool has built in pressure release button
• Extremely quiet crimping operation, minimal vibration
• Motor ventilation
• Battery condition displayed after every crimping operation
• Durable moulded body offering high resistance to wear
• Ni-MH rechargable battery offering better environmental compatibility

• Cembre Crimp Tool B35-45D accepts many of the dies that are common to 45kN Cembre Hydraulic Crimping Tools

• Specific dies for crimping 120sqmm and 150sqmm are available for the Cembre B35-45D Hydraulic Crimp Tool

Cembre are world leaders in the manufacture of copper and aluminium cable connectors, splices and lugs for LV-HV cable jointing and termination.

Cembre tools cut and crimp underground cables and overhead lines - hydraulic, ratchet and battery operated tools. Cut or crimp EPR, PILC, XLPE, PVC insulated cables with copper or aluminium conductors, lead sheath, steel wire armour ( SWA) or steel wire braid (GSWB). Also - ABC, AAAC and ASCR conductors.

T&D UK are Main Distributors of the complete Cembre range.

Cembre are world leaders in the manufacture of copper and aluminium cable connectors, splices and lugs for LV-HV cable jointing and termination.
