66kV High Voltage Cable Jointer Using Alroc Tools To Strip XLPE Cable Insulation

By Chris Dodds on 18th February, 2016

Follow @ThorneanDerrick

Pictured : 66kV Cable Jointer Using Alroc Stripping Tools To Remove XLPE Insulation.

The underground high voltage power cables protected by Class 1 cable duct are being stripped and prepared prior to terminating into 66kV substation switchgear.

Image : Smith Bros Contracting

T&D are leading distributors of MV Jointing Equipment and are approved suppliers for 3M Cold Shrink, SPS Heat Shrink and Nexans Euromold EPDM Rubber type cable joints, terminations and connectors for 11kV-33kV medium voltage distribution networks.
