PowerProtect Class 1 33kV Cable Duct - Emtelle Ducting Systems

High Voltage Power Cable Duct - 33kV Class 1

Emtelle PowerProtect+ Duct Systems provides reliable underground protection to 33kV high voltage power cables (Class 1)

The challenges the industry faces are well known : a relentlessly rising demand for electricity ; constantly shifting usage patterns ; cities undergoing rapid business and housing development ; and new commercial and residential sites being built daily. This combination of mushrooming demand and fast-changing user demographics is putting electricity providers under increasing pressure. When we factor in the need to build these new networks with the minimum disruption to customers living in these cities, and the affect of industry legislation on construction practices, in conjunction with the latest generation of power cables operating at elevated temperatures, the need for a new generation of cable duct systems to meet these challenges was evident.

In response to these challenges Emtelle has developed a comprehensive range of PowerProtect+ Duct Systems and accessories designed to cope with the stringent demands involved in establishing underground power cables.

Pictured: Emtelle PowerProtect Cable Duct Systems, Class 1 33kV

Emtelle Class 1 & Class 2 HV High Voltage Power Cable Duct 33kV

Class 1 Solid Wall uPVC Cable Duct System guaranteeing 450N compression performance at operating temperatures up to 75 Degrees C. Class 2 Solid Wall uPVC Cable Duct System guaranteeing 450N compression performance at operating temperatures up to 50 Degrees C. Coiled Solid Wall HDPE Cable Duct Systems for service cables and specialist applications.

Emtelle Class 1 PowerProtect+ PVC Cable Ducting 33kV

• Emtelle PowerProtect cable duct withstands compression forces from carriageway loading at elevated temperatures.
• Ease of cable duct installation with integral jointing system, making the product simple to install, therefore ensuring system is installed correctly without fail.
• Ease of cable placement, with low friction inner surface and bespoke long radii bends to meet the requirements of the latest generation cables. This reduces whole system costs as longer high voltage cabling distances can be achieved, resulting in reduction in expensive joints. Internal chamfer on all spigot ends of cable ducts ensures no damage during cable placement, which in turn improves cable lifespan
• Enhanced high voltage cable performance through efficient heat dissipation offered by uPVC duct systems, due to the high compression to wall thickness ratio, compared with alternate systems.
• Comprehensive product range, covering all possible cable requirements and construction techniques, this includes 33kV high voltage power cables.
• Systems are re-useable when cables are replaced or repaired, therefore maximizing asset life and reducing further disruption to the roadways and footways.

Emtelle PowerProtect+ Duct Systems are now specified and used by all major Distribution Network Operators including: EDF, YEDL/NEDL, United Utilities, Scottish Power, Scottish & Southern Energy, Western Power, NIE and ESB Ireland
