132kV EHV Gas Filled Straight Joint With Pfisterer Connex Size 6 Connectors

By Chris Dodds on 18th February, 2016

Follow @ThorneanDerrick

Pictured : 132kV Pfisterer Straight Joint Coupled With Pfisterer Connex Size 6 Plugs

Image Courtesy : Richard Mason (EHV Cable Jointer) - Global Cabling Services Ltd.

Richard Mason is a leading name in the UK EHV Cable Jointing industry - a great guy and great jointer with proven track record across high profile projects installing leading products such as Pfisterer, 3M, Tyco Raychem, ABB and Nexans.



T&D are Main Distributors & Stockists for the Pfisterer range of Medium Voltage Power Products including Connex Plugs, Cable Jointing Tools, Sicon Connectors, Surge Arresters and Electrical Safety Equipment.
