2017 Price List - NERS & Utility Contractors

By Chris Dodds on 2nd February, 2016

Follow @ThorneanDerrick



11kV Triplex Terminations & Cable Joints



• 1TIS-12TX-B 11kV 95-185sqmm Termination   £122.92 set of 3

• 1TIS-12TX-C 11kV 300sqmm Termination   £138.69 set of 3

• SPJ12TX-95-185-1 95-185sqmm Joint   £85.30 per single phase

• SPJ12TX-185-300-1 300sqmm Joint   £94.89 per single phase

• Prices exclude VAT - delivery ex stock

Instruction & Specification

• Termination
• Joint

All terminations include cable gland (bolt-on type - compression optional), universal bushing boots and Pfisterer Sicon mechanical shearbolt cable lugs.

All joints include Pfisterer Sicon mechanical connectors.

SPS heat shrink cable joints and terminations are Tested to International Standards outlined in Cenelec HD 628 S1 and 629.1 S2 : 2006 - encompassing VDE 0278 and IEC 60502 - peace of mind performance.

The following Video shows the Triplex Termination kit contents:

T&D UK have an exceptional track-record in servicing the power industry with LV MV HV electrical, cabling and infrastructure products to enable the construction, maintenance and repair of electricity networks.

T&D provide competitive prices, delivery and first-class customer service :

• LV MV HV Cable Jointing & Cable Terminating
• 11kV 33kV Cable Joints & Cable Terminations - Cold Shrink & Heat Shrink
• Substation Earthing & Lightning Protection
• Cable Jointer Tooling
• Cable Pulling & Laying Equipment
• Underground Cable Protection
• Cable Duct - Power & Telecom
• Cable & Pipe Duct Seals & Transits
• Electrical Safety (Substations & Overhead Line)
• Arc Flash Clothing & Protection
