 Abtech ZAG

LV Electrical Enclosures & Junction Boxes

 ATEX & IECEx Ex ‘e’ (Zone 1 & 2), Ex ‘nA’ (Zone 2)

Class 1, Div 2 (CSA, UL & FM)

Abtech ATEX & IECEx Rated LV Electrical Enclosures







Abtech ZAG aluminium electrical enclosures and junction boxes are ATEX certified and suitable for Zone 1 and Zone 2 hazardous areas.

Abtech ZAG enclosures are available in 19 diffferent sizes manufactured from precision die cast in Al Si 12 grade (LM24) aluminium alloy – the ambient temperature of ZAG range is from -70°C to 130°C.

The Abtech ZAG aluminium range of hazardous area enclosures feature excellent ingress protection qualities meaning this enclosure has been tested and passed IP65/IP66/IP67.

Aluminium enclosures arehazardous area certified ATEX and IECEx Ex ‘e’ (Zone 1 & 2), Ex ‘nA’ (Zone 2) and Class 1, Div 2 (CSA, UL & FM).

Pictured: Abtech ZAG LV Hazardous Area (ATEX & IECEx) Electrical Enclosures Range

Abtech ZAG LV Hazardous Area (ATEX & IECEx) Electrical Enclosures

The Abtech ZAG range of aluminium enclosures and junction boxes have many features for use in a wide range of electrical applications - including industrial and hazardous area junction boxes and OEM applications where the excellent machining qualities of aluminium are preferred.

The Abtech ZAG range of aluminium enclosures and junction boxes can be machined, drilled, tapped with various thread forms and readily accepts most paint finishes and colours. Standard earthing is achieved via external/internal stainless steel studs.

Abtech ZAG enclosures can be supplied fitted with cable terminals or as empty junction boxes. Rail mounted earth terminals or customised earth bars can be fitted inside the electrical enclosure.

Pictured : Abtech ZAG Aluminium Electrical Enclosures & Junction Boxes

 Abtech ZAG Aluminium Enclosures & Junction Boxes


Abtech Aluminium Electrical Enclosures & Junction Boxes - Features

  • Wide Operating Temperature (- 65ºC to +150ºC) (-85°F to +302°F)
  • Ingress Protection up to IP67
  • Painted and Unpainted versions
  • Impact Resistant > 7 Nm
  • Corrosion Resistant
  • Can be drilled and tapped to accommodate most thread forms (NPT for example)
  • Certification for use in Zone 1 and 2
  • UL, CSA, IEC Ex, ATEX, FM, InMetro and TR CU Approvals
  • Ideal for Petrochemical and Marine applications



Allen Head Fixing Screws Allen Head Fixing Screws Standard DIN Rail MountingStandard DIN Rail Mounting Internal Earthing Bars With ClampsInternal Earthing Bars With Clamps



Earth Studs (Brass or Stainless Steel)Earth Studs (Brass or Stainless Steel) External Enclosure HingesExternal Enclosure Hinges Unpainted Raw Finish EnclosureUnpainted Raw Finish Enclosure



Hazardous Area Certified Aluminium Enclosures & Junction BoxesATEX Junction Box Electrical Enclosure

Abtech ZAG enclosures and junction boxes carry global hazardous area certifications - ATEX EEx'e' to BSEN50019 (Zone 1 & 2), EEX'nA' to BSEN50021 (Zone 2), NEMA 4X (CSA, UL & FM Class 1 Div 2).

Abtech ZAG Junction Boxes Selection Table

If in doubt, please contact T&D for specification support and selection advice about hazardous area junction boxes and enclosures.

Abtech Part Number Width (mm) Height (mm) Depth (mm)
ZAG1 50 45 30
ZAG2 58 64 34
ZAG3 98 64 34
ZAG4 150 64 34
ZAG5 75 80 57
ZAG6 125 80 57
ZAG7 175 80 57
ZAG8 250 80 56
ZAG9 122 120 80
ZAG9/9 122 120 90
ZAG10 220 120 80
ZAG10/9 220 120 90
ZAG11 160 160 90
ZAG12 260 160 90
ZAG13 360 160 90
ZAG14 560 160 90
ZAG15 202 230 110
ZAG16 330 230 110
ZAG21 120 360 80
