London Underground Approved Cable Containment from Unitrunk

Unitrunk Cable Tray, Ladder, Trunking & Basket

LU London Underground Approved





Unitrunk are delighted to announce that they have obtained approved product status from a number of its cable management ranges.

Providing product to London Underground projects demands compliance to the most rigorous standards.

Strict quality controls and demanding installation criteria requires products and service that meets the highest standards.

To have Transport for London approve products to be included on the product register makes a clear statement as to the quality of those products.

It is a benchmark for consultants or contractors assessing the suitability and durability of products.

Unitrunk - London Underground

Unitrunk met the challenge head on when, a couple of years ago although not on the approved product register, they were specified to manufacture and supply a range of bespoke single and multi - compartment trunking for a communications, P.A and Fire alarm project.

Unique installation requirements resulted in over 480 bespoke components being manufactured, a dedicated on site engineer and design team provided the solutions.

The products approved with their respective LU London Underground reference numbers are:

Unitrunk Products Approved For LU London Underground
Product ID Type Description Image
Unitrunk 1815 Unitrunk Trunking - Standard

A complete range of trunking and fittings manufactured to standards as described in BS EN 50085-1:2005.

Manufactured in best quality hot dipped galvanised sheet steel to BS EN 10346:2009 giving maximum protection from corrosion

Unitrunk Trunking - Standard
Unitrunk 1815 Unitrunk Trunking - Multi Compartment

Bends and tees are supplied with necessary dividing fillets.

Top lid tees and 4 way intersections are supplied with cross-over bridges.

Unitrunk Trunking - Multi Compartment
Unitrunk 1816 Unitrunk Lighting Trunking

Manufactured from galvanised sheet steel to BS EN 10346: 2009.

Unitrunk Lighting Trunking
Unitrunk 1817 Unitrunk Cable Tray

Available in light, medium and heavy patterns produced in pre-galvanised mild steel to BS EN 10346:2009 or galvanised in accordance with BS EN ISO1461.

Unitrunk Cable Tray
Unitrunk 1819 Unitrunk Cable Ladder

Conforming to BS EN 61537:2007 Speedway Cable Ladder is a major advance in cable ladder design

Provides faster and easier installation with a unique coupler locking system and a comprehensive range of accessories.

Unitrunk Cable Ladder

Unitrunk 1820

Unitrunk Cable Tray Basket

EasyConnect Cable Basket system adheres to the Rapid Installation Systems philosophy.

The integral coupler simply pushes together to form a secure joint - no additional couplers or special tools required.

Unitrunk Cable Tray Basket
Unitrunk 1822

Unitrunk Channel and Supports

Interlok Channels are made in deep, shallow, plain, slotted and multiple combination profiles in accordance with BS 6946.

Standard lengths are 3 and 6 metres, with a wide range of other lengths, brackets and beam clamps available.

Unitrunk Channel and Supports

Link-Up



T&D are Link-up Registered and Approved Vendors to Network Rail and TfL London Underground (LU).
