T&D Working with Ellis Patents on New Aramco Project

By Chris Dodds on 31st August, 2012

Follow @ThorneanDerrick



Ellis Patents Cable Cleats

Ellis Patents Single Hole Aluminium Cable Cleats



Thorne & Derrick are working with Ellis Patents to achieve cable cleat acceptance and project specification at the Yanbu Red Sea Refinery for end client Saudi Aramco.

T&D have proposed Ellis Patents aluminium single cable cleats for retaining and supporting 34.5kV high voltage single core XLPE cables.

Pictured: Ellis Patents Single Hole Aluminium Cable Cleats

Project Spotlight: The Yanbu Export Refinery Project (YERP) is a new “grassroots” refinery with a capacity to process 400,000 bpd of Arabian Heavy crude and produce 90,000 bpd of gasoline, 263,000 bpd of ultra-low-sulfur diesel, 6,300 metric tons per day (mtd) of coke and 1,200 mtd of sulfur.

The new refinery will use existing Saudi Aramco facilities to receive crude oil and export the refined products. It will include refinery process units, utilities and interconnecting piping, associated feedstock and refined product storage, as well as offsite facilities necessary to support the safe and efficient operation of the refinery.


Pictured: Yanbu Red Sea Refinery

Client Spotlight: Saudi Aramco (Arabic: أرامكو السعودية‎ ʾArāmkū s-Suʿūdiyyah), officially the Saudi Arabian Oil Company, is the national oil company of Saudi Arabia.

Saudi Aramco was estimated to be worth $781 billion in 2005, making it the world's most valuable company. Saudi Aramco has both the largest proven crude oil reserves, at more than 260 billion barrels (4.1×1010 m3), and largest daily oil production.

Headquartered in Dhahran, Saudi Arabia, Saudi Aramco operates the world's largest single hydrocarbon network, the Master Gas System. Its yearly production is 7.9 billion barrels (1.26×109 m3), and it managed over 100 oil and gas fields in Saudi Arabia, including 279 trillion scf of natural gas reserves.

Saudi Aramco owns the Ghawar Field, the world's largest oil field, and the Shaybah Field, one of the world's largest oil fields.



• Further Reading

Ellis Emperor Cable Cleats For 11kV High Voltage Substation Cables (UKPN Approved)
