Cresatech ZS CuTs Copper Theft 1 of 2 : For Monitoring of Copper Grounded Systems

By Chris Dodds on 19th February, 2016

Follow us on LinkedIn

Cresatech ZS CuTs Copper Theft  1 of 2 :  For Monitoring of Copper Grounded Systems

Cresatech

Products & Services For Power Utility Networks

The Cresatech CuTS system for monitoring copper grounded and earthed site infrastructure is designed to monitor changes to the system that occur when cut, damaged or degraded.

This system uses sense wire inputs and the monitored infrastructure is coupled into a sensing circuit which detects minor changes (down to below 0.02 micro Henrys). If any change occurs beyond the acceptable threshold, an alarm is activated alerting the user to the changes.

The scalable solution allows real time notification of service disruptions and removal - all of which minimises service down time, enhances site safety and ensures customer service is not interrupted.

Pictured: Cresatech CuTS System For Monitoring of Grounded Site Infrastructure

Cresatech CuTS System For Monitoring of Grounded Site Infrastructure

The Cresatech Managed Service

Cresatech’s managed service provides secure access to all of the functionality of the CuTS devices over wireless networks. Alerts can be managed quickly and effectively using a traffic light system.

The elements of this service are:

  • Wireless Device Management:- management of the CuTS units over any network via a secure IPSEC VPN
  • Graphical User Interface: map views and lists with easy to use tiles showing all alerts, enabling a rapid response to any situation. Accessed via secure IPSEC VPN
  • Alert Management: CuTS: tamper, power, battery and communications alerts with context sensitive menus
  • Asset Tracking: database of every CuTS® unit and module, with site ID if deployed
  • Installation and configuration: support for installation engineers with access to configuration window for each device and best practice Wiki
  • Maintenance Management: maintenance status with alarm suppression
  • Application Integration: Integration capabilities for data and management functions via REST APIs

Pictured: Cresatech CuTS System - Wireless Infrastructure Management

Cresatech CuTS System - Wireless Infrastructure Management

CuTS Systems Provides An Immediate Alarm On Removal Of Protected Infrastructure On The Site.

Pictured: Cresatech CuTS Copper Metal Theft Detection System

Cresatech CuTS Copper Metal Theft Detection System



  • Further reading :

Cresatech ZM CuTs Copper Theft 2 of 2 : For Monitoring of High Voltage Substations

Mitigating Risks Caused By Metal Theft In Electrical Transmission & Distribution Networks
