6 Way Earth Bars AN Wallis

By Chris Dodds on 23rd September, 2014

Follow @ThorneanDerrick

Earth Bars for Earthing & Lightning Protection.

Today, we have up-loaded 3 short display videos showing the 3 types of copper earth bars available - standard, single-link and twin-link earth bars.

AN Wallis Earth bars are manufactured from 50 x 6mm hard drawn copper bar to BS EN 13601 with 4, 6, 8, 10, 12, 14, 16, 18 and 20 way brass M10 stud assemblies. Standard copper earth bars are available with the option of single or twin disconnection links. Copper earth bars with disconnection links offer a temporary break in the connection to earth allowing the testing and isolation of multiple earth rod systems. Tinned copper earth bars are also available for industrial earthing applications, such as waste water treatment plants.

Customised earth bars are available according to client specification including 600amp and 1000amp heavy power earth bars. AN Wallis manufacture earth bars to your requirements using quality copper components. Any size of copper earth bar can be sourced, fixing materials changed and channel bases can be redesigned to enable a product to be engineered that meets your exact earthing protection requirements.

Wallis copper earth bars recommended fixing is by countersunk wood screw 1½" x No. 12 and No. 12 wall plug.



Video: Earth Bars AN Wallis - 6 Ways EBC006 Standard



Video: Earth Bars AN Wallis - 6 Ways EBC106 c/w Single Disconnection Link



Video: Earth Bars AN Wallis - 6 Ways EBC206 c/w Twin Disconnection Links

6 Way Earth Bars AN Wallis
