3M Cold Shrink LO42- Network Rail 750V Track Feeder Cable Joints

By Chris Dodds on 29th May, 2013

Follow @ThorneanDerrick

3M Network Rail Specification Cold Shrink Inline Joints & Terminations - 450/750V Track Feeder Cables to RT/E/S/21101.


3M Rail Cable Joint Termination Kit Reference: LO42

Application: Inline Cable Joints Terminations 161/240sqmm

Minimum cable diameter: 15.2mm

Maximum cable diameter: 61mm

Cable joint termination length: 457mm

3M LO42 Cold Shrink Tube cable joints are suitable for jointing AEI type track feeder cables with CSP over sheath and stranded tinned copper or aluminium conductors. Track feeder cables can provide the 450/750 volt DC supply from traction substations to conductor rails, negative cable connections and where appropriate bonding.

T&D stock 3M LO42 Cold Shrink Tube Joints & Terminations with Network Rail Approval.

T&D are Link-up Registered and Approved Vendors to Network Rail and TfL London Underground (LU).

Category:  Rail
