3M LO42 Cold Shrink Inline Joint Termination, Network Rail Approved

3M Cold Shrink Inline Joints & Terminations

3M Scotchcast Kit LO/42

Network Rail Specification

3M Cold Shrink Cable Sealing Tubes are specified for rail cable sealing, insulation and protection and are approved by Network Rail for live rail terminations and inline joints for DC track feeder cable applications.

3M Cold Shrink provides a permanent radial seal, expanding and contracting with the rail cable under load conditions

3M Cold Shrink Tubes are made from EPDM rubber, expanded onto a removable supporting plastic core.

3M Scotchcast Kit LO/42 Network Rail Product Specifications

Application	Kit	Minimum Cable Diameter	Maximum Cable Diameter	Cable Joint Termination Length
161/240mm2 Inline joints or terminations	LO/42	15.2mm	61mm	457mm



As the core is unwound, the 3M Cold Shrink insulating sleeve shrinks to form a tight seal around the cable terminal or splice.

Video: 3M LO-42 Cold Shrink Joints & Terminations For Track Feeder Network Rail Cables

LO42 - 3M Cold Shrink, Network Rail Inline Cable Joint / Termination
