Copper Earth Plates

Earthing & Lightning Protection

Copper Earth Plates, Solid Copper

Material: Copper manufactured to BS EN 12163 (formerly BS 2874)

AN Wallis Earthing & Lightning Protection Distributors

Solid copper earth plates provide a long lasting earthing solution in places where driving earth rods might be impractical  - they are often installed in conjunction with low resistance earthing compound or Bentonite earthing compound.

T&D offer a full range of Wallis earthing & lightning protection products.

Solid Copper Earth Plates are manufactured to BS EN 12163 (formerly BS 2874) – copper lattice earth mats are also available.

Pictured: Wallis Copper Earth Plates (Material conforms to BS EN 12163)

Wallis Copper Earth Plates - Product Range

Part Number	Dimensions	Surface Area	Unit Weight	Pack Quantity
EMP 601	600mm x 600mm x 1.5mm	0.73m²	4.80kg	1
EMP 603	600mm x 600mm x 3mm		9.60kg	1
EMP 901	900mm x 900mm x 1.5mm	1.63m²	10.80kg	1
EMP 903	900mm x 900mm x 3mm		21.60kg	1
