Copper Earth Plates (Solid Copper Type) 600x600x3.0mm - Wallis EMP603

Earth Plates - Solid Copper Earth Plate

Length 600mm

Width 600mm

Height 3mm

Wallis EMP 603 Copper Earth Plate

Solid copper earth plates provide a long lasting earthing solution in places where driving earth rods might be impractical - copper earth plates are often installed in conjunction with low resistance earthing compound or Bentonite earthing compound.

BS EN 13601:2013 Standard – Copper and Copper Alloys. Copper rod, bar and wire for general electrical purposes.

• Earth Plate Length x Width: 600mm x 600mm
• Height: 3.0mm
• Surface area: 0.73sqmm
• Unit Weight: 9.60kg
• Order Code: AN Wallis EMP603 (Copper)

Pictured: Wallis Copper Earth Plates EMP 603

Wallis EMP 603 Copper Earth Plates - Product Details

Part Number	Dimensions	Surface Area	Unit Weight	Pack Quantity
EMP 603	600mm x 600mm x 3mm	0.73m²	9.60kg	1



Bentonite Conductive Earthing Compound
