Brass Wiping Cable Glands (Cones) For Earthing Lead Sheathed MV-HV Power Cables

By Chris Dodds on 20th November, 2015

Follow @ThorneanDerrick

High Voltage Electrical Equipment.

Brass wiping glands are used to gland and mechanically earth the lead sheath (Pb) on medium-high voltage power cables.

Brass wiping cones or wiping glands are earth glands used to plumb lead sheath cables, usually 11kV PILC.

The brass wiping gland kit includes : brass cone, bolt pack, heatshrink sleeve and jubilee clips for cable armour clamping.

• B1142/1 Size X Brass Cable Wiping Gland - 60mm Diameter BS2562
• B1142/3 Size Y Brass Cable Wiping Gland - 89mm Diameter BS2562

Please click here for more information: Brass Wiping Glands

Video : Brass Wiping Cable Glands for LV HV Power Cables
