3M Scotchcast Resin Cable Joints for Low Voltage Cable Jointing.
T&D stock the complete range of 3M Scotchcast Resin Cable Joints for armoured, braided and unarmoured low voltage power, control and instrumentation cables.
3M Scotchcast resin (470W) cable joints are designed to cable joint multi-core armoured (SWA or GSWB), polymeric (XLPE EPR) low voltage power cables - 3M cable joints provide electrical insulation and mechanical protection with either compression or mechanical connectors - 3M LVI-1 power cable joints have now replaced the 3M LA range of cable joints.
3M LVI-1 Resin Cable Joint Kits - Maximum Cable ODs (mm)
LVI-1/2 Resin Joint - 25mm
LVI-1/3 Resin Joint - 32mm
LVI-1/4 Resin Joint - 36mm
LVI-1/5 Resin Joint - 45mm
LVI-1/6 Resin Joint- 54mm
LVI-1/7 Resin Joint - 64mm
LVI-1/8 Resin Joint - 77mm
3M LVI-1 Scotchcast Resin Power Cable Joints - Features
*Scotchcast 470W resin with integrated closed mix and pour (CMP)
*One part cable joint mould with snap-fit closing for quick and easy jointing
*Pre cut foam sealing elements for wide range cable diameter applications
*Closure cap on cable joint shell to prevent pollution
3M Benefits - LV Resin Cable Joints
Safe - integrated resin pour (no spill, no waste) eliminates direct skin contact
Simple - one part, click fit joint shell enables rapid installation
Speed - unique design and earth continuity system saves installation time
Strength - high quality resin exceeds strength of cable when pulled
Stock - immediate delivery from T&D stocks at competitive prices
Power, Control, Pilot & Instrumentation Cable Joints...
Construction - BS5467, BS6724, BS7889, BS5308, BS6387, 6491X
Oil, Gas, Petrochem - EEMUA133, BS5308, UK00A, BS6883, BFOU, NEK606
Rail - NR Track Feeder Power, Signal, Points Heating Cables (PADS)
Mines & Quarries - BC295, BS6708, 307M Flexible & Trailing Cables
Ports - Power & Control Flexible Reeling Crane Cables
Motorway & Street Lighting - Highways Agency & NMCS Cables
Marine Offshore - BS6883, NEK606, IEC60092, IEC60331, RFOU/BFOU
![]() | 3M Scotchcast Cable Joints - LV Cable Joints Selection Guide |
