11kV Flexible Rubber Reeling Vulcanised Cable Joint

By Chris Dodds on 14th September, 2015

Follow us on LinkedIn

11kV Flexible Rubber Reeling Vulcanised Cable Joint

Picture Courtesy : Corey Caulfield

  • Director/Cable Jointer -  HV Connect Pty Ltd

This vulcanised type cable joint is smooth profile preventing "snagging" of the 11kV joint during the reeling process - there is absolute minimal increase to the overall outside of the cable diameter despite the joint.

"The cable joint was completely taped using a variety of 3M Scotch vulcanising tapes and the outer sheath was re-instated using Prysmian rubber tape. A complete cable joint carried out on a stacker," said Corey.

3MPrysmian

HV Jointers



11kV Vulcanised Cable Joint
