High Voltage Junction Boxes

Abtech

ATEX Electrical Enclosures & Junction Boxes for Hazardous Areas

Zone 1 & Zone 2 Enclosures & Junction Boxes LV HV

Abtech HV Junction Boxes ATEX Rated





Abtech HV Junction Boxes Range

T&D can produce custom designed high voltage junction boxes for cable connection applications in safe and hazardous areas (Zone 1 and Zone 2).


Abtech MJB - High Voltage Junction Boxes
MJB high voltage junction box provides a simple, low cost but effective solution for terminating HV cables up to 8.3kV.

Protection : IP66 IP67
Certification : ATEX EEx e (Zone 1 & Zone 2)
                     ATEX EEx nA (Zone 1 & Zone 2)
                     ATEX EEx nR (Zone 1 & Zone 2)
                     Deluge Tested to DTS-01
Material : Stainless Steel 316 or Mild Steel

Abtech DPJB - High Voltage Junction Boxes
DPJB high voltage 'down hole pump' junction box provides a effective solution for terminating HV cables up to 11kV.

Protection : IP66 IP67
Certification : ATEX EEx e (Zone 1 & Zone 2)
                     Deluge Tested to DTS-01
Material : Stainless Steel 316 or Mild Steel

Abtech HVJB - High Voltage Junction Boxes
HVJB high voltage junction box provides an enhanced flexibilty solution for terminating HV cables up to 33kV.

Protection : IP66 IP67
Certification : ATEX EEx e (Zone 1 & Zone 2)
                     Deluge Tested to DTS-01
Material : Stainless Steel 316 or Mild Steel

Abtech LR - High Voltage Junction Boxes
LR high voltage junction box provides an specialist application solution for terminating HV cables up to 11kV.

Protection : IP66 IP67
Certification : ATEX EEx e (Zone 1 & Zone 2)
                     Deluge Tested to DTS-01
Material : Stainless Steel 316 or Mild Steel

High Voltage Junction Boxes - Abtech BUSBAR BOX
Busbar enclosures provide a solution for connecting 3 phase & neutral and up to 6 cables per phase. HV cables up to 11kV.

Protection : IP66 IP67
Certification : ATEX EEx e (Zone 1 & Zone 2)
                     Deluge Tested to DTS-01
Material : Stainless Steel 316 or Mild Steel



T&D stock and distribute an extensive range of High Voltage Cable Terminations, Plugs & Cable Connection Systems up to 33kV for polymeric (XLPE EPR) and paper (PILC) insulated cables - 3M Cold Shrink Terminations, Prysmian Heat Shrink Terminations, SPS Heat Shrink Terminations, Nexans Euromold Screened Separable Connectors and Pfisterer Inner Cone Plugs compatible with air and gas insulated switchgear manufactured by ABB, Siemens, Eaton Alstom, Brush, Schneider and Hawker Siddley.

Electrical system designers and contractors should be attentive to the short circuit forces generated by high voltage power cables and select cable cleats to provide cable support and containment - Ellis Patents Cable Cleats provide reliable cleating of high voltage cables, 11-33kV.

Adobe Abtech Cable Glands and Adaptors - Hazardous Area Catalogue

Adobe High Voltage Junction Boxes - Industrial & Hazardous Area (Zone 1 & 2)
