Cable Lugs & Splices

Jointing & Terminating MV HV Cables

BICC BICON





Prysmian BICC BICON BTHW and BTH copper crimp lugs and splices are specified for terminating and jointing high voltage cables 11kV to 33kV - the abscence of an inspection hole and presence of internal waterblocking resin prevents moisture ingress.

T&D UK distribute Prysmian crimp connectors and associated crimping tools.

Compression Connectors for Connecting & Terminating MV HV Conductors11kV 33kV
Compression (crimp) connectors are an established method of connecting and terminating medium-high voltage cable conductors (11kV 33kV).

To ensure a reliable connection or termination, the following should be observed.

  • Both cable conductor and compression crimp should be cleaned down using cable cleaning wipes
  • The size, shape and metal (copper or aluminium) must be correct for the cable conductor
  • The correct crimp die set should be selected
  • The cable conductor must be fully inserted into the crimp connector
  • The correct compression or crimping sequence must be followed and the full compression pressure applied

Failure to observe these precautions can result in a compression connector, lug or termination that fails in service.



Pictured : Prysmian Connectors. BICON BICC copper cable lugs, reducer splices and through splices are used to crimp, joint and terminate 11kV and 33kV stranded copper power cables.

Prysmian Lugs Prysmian Reducer Splices Prysmian Splices
