BICC BICON BTHW Lugs





Prysmian BICON BTHW range of copper cable lugs are designed for medium-high voltage (11kV-33kV) 11kV 33kV Lugscable terminating applications - the absence of an inspection hole and internal waterblocking polyurethane seal prevents moisture ingress into the cable lugs and subsequently into the medium-high voltage cable conductor.

Prysmian BICON BTHW copper cable lugs are made from thick wall electrolytic seamless copper tube, featuring an extended cable lug barrel and knurled marks to indicate crimping die set positions for medium-high voltage cable jointers.



Prysmian BICON BICC Copper Cable Lugs - BTHW Specification

Prysmian cable lugs (BICON) are manufactured from thick wall high purity oxygen free copper tube which is subsequently tin plated and waterblocked for low and high voltage cable connections. The waterblock or waterproof cable seal, is provided by adding a small quantity of polyurethane resin to the base of the compression barrel. Prysmian die set and catalogue numbers are marked on the cable lug connector. The compression barrels have knurl markings to indicate crimp positions.

Prysmian terminals are suitable for indoor or outdoor applications and are installed by circumferential crimp die sets. The extended barrel and smooth compressions are particularly suitable for the application of protective sleeving. Suitable for low voltage and high voltage installations 11kV-33kV.

T&D UK are Prysmian Distributors for the complete range of cable accessories including joints, cleats, glands and terminations.

Prysmian BICON Medium-High Voltage (MV-HV, 11-33kV) Copper Cable Lugs
Part No Conductor Application (stranded conductor) mm² Stud Size (mm) C (mm) N (mm) L (mm) Z (mm)
BTHW50C12 50 12 24.5 69.2 11.9 14.4
BTHW70C12 70 12 27.6 71.0 11.9 14.4
BTHW95C12 95 12 27.2 78.0 11.9 14.4
BTHW120C12 120 12 32.0 90.6 14.4 14.4
BTHW150C12 150 12 32.0 91.6 14.4 14.4
BTHW185C12 185 12 32.0 95.6 14.4 14.4
BTHW185C16 185 16 32.0 101.6 17.4 17.4
BTHW240C12 240 12 41.5 107.2 14.4 14.4
BTHW240C16 240 16 41.5 113.2 17.4 17.4
BTHW300C12 300 12 45.0 107.2 14.4 14.4
BTHW300C16 300 16 45.0 113.2 17.4 17.4
BTHW400C16 400 16 50.0 125.5 20.6 17.4
BTHW400C20 400 20 50.0 135.4 28.3 19.9
BTHW500C12 500 12 55.5 136.8 20.6 17.4
BTW630C16 630 16 62.7 173.0 27.0 28.0
BTW630C20 630 20 62.7 173.0 27.0 28.0
