3M Network Rail Cold Shrink Joints for Track Feeder Cables

3M Cold Shrink Joints - Network Rail





3M Cold Shrink Network Rail cable joints are used for the cable jointing and cable terminating of track feeder cables.

3M Cold Shrink cable joints require no hot-work permit or special tools for installation.

Track feeder cable joints are approved for cable jointing Network Rail NR/PS/ELP/21101, BS6360 and BS6899 specification single core copper and aluminium cables, 650/750 DC supply.

CSP sheathed track feeder cables provide power supply from the substation to the rail track side.

3M Cold Shrink Cable Sealing Tubes are specified for rail cable sealing, insulation and protection and are approved by Network Rail for live rail terminations and inline cable joints for DC track feeder cable applications.

3M Cold Shrink provides a permanent radial seal, expanding and contracting with the rail cable under load conditions.

3M Cold Shrink Tubes are made from EPDM rubber, expanded onto a removable supporting plastic core.

As the core is unwound, the 3M Cold Shrink insulating sleeve shrinks to form a tight seal around the cable terminal or splice.

3M Network Rail Cold Shrink Joints for Track Feeder Cables

Cable Joint/Termination Application	Cable Joint Kit	Min Diameter	Max Diameter	Cold Shrink Length
500/630/1000mm² 3rd Rail Terminations	LO41	24.4	98.2	228mm
161/1240mm² Inline Joints or Terminations	LO42	15.2	61	191mm
500/630/800/1000 Inline Joint	LA11	38.1	114	457mm

Video : 3M Cold Shrink Joints & Terminations For Track Feeder Rail Cables - 3M LO-42
