CATU CM-4000 High Voltage Insulating Sticks

CATU High Voltage Insulating Sticks

CATU CM-4000

Hot Sticks : IEC 60855 Foam Filled Insulating Sticks

CATU CM-4000 hot sticks are insulating sticks compliant with IEC 60855 - foam filled hot sticks are very strong and rigid by design.

CATU CM-4000 insulating sticks comprise of basic (bottom section) with hand guard, intermediate section and terminal top section with choice of fittings to suit voltage detector or tool being located to the end of the hot stick.

Hot sticks are suitable for manoeuvering voltage detectors and short-circuit and earthing systems.

Pictured: CATU CM-4000 High Voltage Insulating Sticks

CATU CM-4000 High Voltage Insulating Sticks

Part Ref	Smallest End Fitting	Biggest End Fitting	Insulating	Weight
Basic
CATU CM-4610	1.13m	-	0.8m	1.35kg
CATU CM-4615	1.63m	-	0.33m	1.8kg
CATU CM-4620	2.13m	-	0.33m	2.8kg
CATU CM-4625	2.63m	-	0.83m	3.3kg
Intermediate
CATU CM-4610-I	1.165m	-	0.8m	1.3kg
CATU CM-4615-I	1.165m	-	1.3m	1.7kg
CATU CM-4620-I	2.165m	-	1.8m	2.6kg
CATU CM-4625-I	2.665m	-	2.3m	3.1kg
Terminal
CATU CM-4610-(*)	1.115m	1.21m	0.78m	1kg
CATU CM-4615-(*)	1.615m	1.71m	1.28m	1.4kg
CATU CM-4620-(*)	2.115m	2.21m	1.78m	2.2kg
CATU CM-4625-(*)	2.615m	2.71m	2.28m	2.7kg
Fixed Sticks
CATU CM-4115-(*)	1.575m	1.675m	0.82m	1.35kg
CATU CM-4120-(*)	2.075m	2.175m	1.07m	1.8kg
CATU CM-4125-(*)	2.575m	2.675m	1.32m	2.8kg
CATU CM-4130-(*)	3.075m	3.175m	1.82m	3.3kg



Hot Sticks - IEC 60855 Foam Filled Insulating Sticks - CATU CM4000

Hot Sticks - Insulating Sticks CATU CM4000

Hot Sticks - Insulating Sticks CATU CM4000 - Fittings
