1.0 EMTELLE PVC DUCT REPAIR KITS : TELECOMS DUCTING GENERAL

1.1 PVC duct repair kits (inc. split-duct) have been developed as a means of repairing telecoms cable ducting systems, which experience the majority of third party damage by other utilities due to the depth of burial of these systems.

1.2 The  PVC duct repair kit application area covered, within this document is telecoms.

1.3 PVC duct repair kits size ranges from 96.5mm to 110mm OD, with tongue and groove connection for split duct to ensure ease of installation and security of repair, following reinstatement of excavation post repair of telecoms cable ducting systems. 53.9mm split duct and repair kits are available upon request - Emtelle can fabricate split duct and repair kits for larger sizes and other applications, also upon request.

1.4 Individual PVC repair kits are supplied in polythene bags, and include an installation guide, these in turn are then packed in non-returnable woven polypropylene sacks, which are bio degradable. Split duct is manufactured in 3m lengths which is cut to size on site to suit the repair required.

1.5 The PVC duct repair kits shall be printed or labelled according to customer requirements and traceable to Emtelle’s ISO 9000: 2000 quality system.

2.0 EMTELLE PVC DUCT REPAIR KITS : TELECOMS DUCTING RAW MATERIALS/ DESIGN INSTALLATION

2.1 Split duct repair kits is manufactured from PVC. Each repair kit length is 3m and is split in 2 to create to half circles, which enables cabled ducts to be repaired. Where the 2 half circles meet the wall of the duct has a tongue at one side and a groove at the other to ensure secure location of the 2 halves pre and post them being secured with cable straps

Duct repair kits : Split Collars – 2no. (4 halves) – PVC
Duct liners - 6no. – Polypropylene
Cable straps – 8no. – Nylon

The combination of a split collar insert and up to 3 duct liners provides compatability for a range of telecoms ducting bore diameters, dependant on the duct repair kit / split-duct size you choose:-

Duct Repair Kit Size  Duct Bore Size Nominal      Duct Bore Range
96.5mm                        96.5mm = 90mm Bore        88mm – 95mm
110mm                         110mm = 103mm Bore       98mm – 105mm

Attention should be paid to the split collar inserts, these are clearly marked SMALL and LARGE diameters respectively, on each spigot end (see diagram). Either spigot end will fit in to the split duct it is designed to be used with. NB – split duct and repair kits should only be used together when the same size eg – 96,5mm split duct with 96.5mm duct repair kits.

2.2 PVC duct repair kits colour is to standard colour range light grey, green, white. Dark grey and orange are also available to order.
