Emtelle Telecoms Cable Duct System Overview
- PVC-U Primary Duct Systems
- HDPE Sub Duct & Duct Systems
- Blown Fibre Tubing
- Cable in Duct
- Multi Duct
Emtelle PVC Duct - Telecoms Ducting
| OD SIZE nominal (mm) |
I>D Nominal/ (mm) |
WALL THICKNESS nominal/ (mm) |
EN 50086 2-4 Compression Strength Classification in Newtons |
EN 50086 2-4 Impact Strength Classification in Joules |
| 54 |
51 |
1.75 |
250 |
|
| 54 |
50 |
2.1 |
450 |
15 |
| 54 |
49 |
2.5 |
750 |
|
| 88.9 |
84 |
2.4 |
250 |
|
| 88.9 |
83 |
2.95 |
450 |
20 |
| 88.9 |
82 |
3.5 |
750 |
|
| 96.5 |
91 |
2.55 |
250 |
|
| 96.5 |
90 |
3.1 |
450 |
28 |
| 96.5 |
89 |
3.7 |
750 |
|
| 105 |
100 |
2.7 |
250 |
|
| 105 |
98 |
3.3 |
450 |
28 |
| 105 |
97 |
3.9 |
750 |
|
| 110 |
104 |
2.8 |
250 |
|
| 110 |
103 |
3.37 |
450 |
28 |
| 110 |
102 |
4 |
750 |
|
| 125 |
119 |
3 |
250 |
|
| 125 |
118 |
3.37 |
450 |
28 |
| 125 |
116 |
4.35 |
750 |
|
| 160 |
153 |
3.6 |
250 |
|
| 160 |
151 |
4.35 |
450 |
40 |
| 160 |
150 |
5.13 |
750 |
|
1.0 EMTELLE PVC CABLE DUCT : TELECOMS DUCTING GENERAL
1.1 Emtelle PVC duct telecoms ducting systems are a solid wall pipe manufactured in accordance with relevant, internationally recognised quality standards under an ISO 9000/2000 quality system.
1.2 The PVC duct telecoms ducting systems application area covered, within this document are telecommunications.
1.3 PVC duct telecoms ducting systems size ranges from 54mm to 160mm OD and includes plain ended and interference fit socket joints
1.4 PVC duct telecoms ducting systems are supplied on non-returnable wooden U-frames. The pipe pallets are designed to be stored on even, stable ground, they must not be stored more than 3 pallets high.
1.5 PVC duct telecoms ducting systems shall be free from surface defects which are material to the pipes physical performance and colour is light stable in UK and Ireland for 6 months external storage unless otherwise agreed by customer specification
1.6 PVC duct telecoms ducting systems shall be printed or labelled according to customer requirements and traceable to Emtelle’s ISO 9000: 2000 quality system.
2.0 EMTELLE PVC CABLE DUCT : TELECOMS DUCTING RAW MATERIAL
2.1 PVC duct telecoms ducting systems raw materials are uPVC resin and other additives suitable for the required properties of the finished product.
3.0 EMTELLE PVC CABLE DUCT : TELECOMS DUCTING DIMENSIONS
3.1 PVC duct telecoms ducting systems shall have dimensions (mm) as per table above, all testing is conducted at +20 degrees C.
3.2 PVC duct telecoms ducting systems compression strength and impact strength test s procedures are as specified in BS EN 50086-2-4.
4.0 EMTELLE PVC CABLE DUCT : TELECOMS DUCTING ERFORMANCE
4.1 PVC duct telecoms ducting systems comply with BS EN 50086/2/4, 250N, 450N or 750N Classifications.
4.2 PVC duct telecoms ducting systems physical measurements have equal importance across application area.
5.0 EMTELLE PVC CABLE DUCT : TELECOMS DUCTING MARKING
PVC duct telecoms ducting systems will be marked with the relevant specification to give durable detail and traceability after installation.
