Prysmian BICON 424TA Explosion Proof Barrier Cable Glands

Zone 1 & Zone 2 Hazardous Areas (ATEX Certified)

Ex d Cable Glands

Prysmian BICON BARR-A Ex d llC - 424TA56



The Prysmian BARR 424TA56 is a barrier type cable gland for unarmoured cables in Zone 1 and Zone 2 hazardous areas which aids the control of mingrating gasses. The BICON 424TA56 BARR-A Exd IIC cable gland provides the highest level of hazardous protection.

Prysmian 424TA56 gland kit suits 17.0mm - 25.4mm diameter cables. Nickel plated cable glands available (424TA-56V). NPT thread lengths comply with UL2225 requirements.

Prysmian BICC 424TA56 Barrier Gland

Prysmian 424TA Series Barrier Cable Gland Specifications
Gland Reference Cable Dimensions (mm) Gland Dimensions
Design Ref Size Metric Max dia.

Max No.

Overall Ø (B)

D

E

F

Hexagon
Min Max

A/F

G

A/C

H

Prysmian 424TA-56 32 22.1 60 17 25.4 M32 x 1.5 15 59 47.2 53.6

Adobe Prysmian 424TA56 Explosion Proof Barrier Glands for Zone 1 Zone 2 Hazardous Areas
