Cable Joints & Hydro Carbon Resistant Performance

3M Cable Joint Kit

Hazardous Area Power Cable Joints

Cable Joints for Offshore Oil, Gas & Petrochemical Cables



An oil company was experiencing problems with the earth continuity of a low voltage feeder.

The problem was narrowed down to a heat shrink cable joint installed between 15-20 years previous and manufactured by a company no longer in business.

On investigation it was obvious the material had not reacted well to the years of hydro carbon attack. The butyl mastic inner fill had turned to a sticky paste and the inner, connector insulation tubes had also suffered.

The cause of the earth continuity problem was due to poor connections onto the wire armours and subsequently liquid rubber isolating the armours from the earth continuity lead.

Even though the cable joint used was not designed to withstand these conditions, it had survived remarkably well, and only failed as a result of hydro carbons, entering the cable some distance away and travelling between the wire armours and inner sheath to the cable joint, and finally attacking the joint from within.

Cable Joints & Hydro Carbon Resistant Performance

3M hazardous area cable joint kits provide long term hydrocarbon resistance in extreme hazardous areas including Zones 1, 2, 21 and 22.

In applications where cables may be subjected to attack from hydrocarbons including oils, solvents, gases or other chemicals, designers and installers of critical cabling systems have historically relied upon using conventional lead-sheathed cable to provide maximum protection.

3M hydrocarbon resistant cable joints are suitable for paper (PILC) and polymeric (EPR, XLPE) insulated cables, with steel wire armour (SWA) or galvanised/phosphur bronze wire braided cables, with or without lead covered cable sheaths.

Further reading : A Shutdown Postmortem - Inevitable Consequences of Cable Damage In The Oil & Gas Industry (Includes Hazardous Area Training Video).

Adobe 3M Scotchcast Resin (1402FR) - Hazardous Area Hydro Carbon Resistant Resin

Adobe 1402FR Hydrocarbon Resistant, Halogen Free, Flame Retardant Resin - IEC60455-2 Test Report

Adobe 1402FR Hydrocarbon Resistant, Halogen Free, Flame Retardant Resin - Currenta Test Report

Adobe 1402FR Hydrocarbon Resistant, Halogen Free, Flame Retardant Resin - RWE Test Report
