   Ellis Patents Cable Cleats

Ellis Patents Vulcan VRT+ stainless steel cable cleats are available for trefoil, single, quad and bundled cable applications where moderate levels of short circuit withstand are required. Vulcan cable cleats are short circuit tested to 43kA rms (93.6kA peak).

Ellis Patents Vulcan VRT+ cable cleats are compliant with London Underground Engineering Standard 1-085 - Product Register No.361.

Max Short Circuit Test Level - Vulcan Cable Cleat Spacing

104kA - 600mm
132kA - 300mm

Vulcan + cable cleats are available for trefoil, single, quad and bundled cable cleat applications where moderate levels of short circuit withstand are required. The unique patented compact cleat design allows easy installation where space is limited.

Manufactured in type 316L stainless steel (BS EN10088:1995), Vulcan cable cleats offer ultimate protection against the harshest environmental conditions.

The cleats are supplied with an M10 stainless steel clamping bolt, an M10 stainless steel flange nut and a low smoke and fume zero halogen polymeric head retainer.

To protect and cushion the cables during short circuit conditions, the cable cleat comes with an integral low smoke and fume zero halogen polymeric liner and removable base pad. Recommended cleat fixing methods include using either one or two M10 bolts (available as extras). A ProTect Intermediate Strap can be fitted between wider spaced cable cleats for more economical installation.

Ellis Patents recommend fixing Vulcan VRT+ cleats using one 10mm bolt for sizes 00 to 09, and one or two 10mm bolts for sizes 10 to 20. For a more economical installation, cable cleats can be spaced more widely, with a retention strap fitted in between.

LUL - London Underground Compliant Ellis Patents Vulcan Cable Cleats to Engineering Standard 1-085, Product Register No. 361 - LUL approved LSF (Low Smoke Fume) zero halogen flame retardant nylon has satisifed LUL limited oxygen, smoke emission and toxic fume emissions tests.


Video : Ellis Patents Vulcan Cable Cleat Test - Trefoil Formation Cable Cleats On Cablofil Cable Basket
