Silver Fox Legend Heatshrink Cable Labels - Low Smoke Zero Halogen

Silver Fox Low Smoke Zero Halogen Heatshrink Cable Labels

Cable Labels & Cable Markers

Silver Fox Thermal Cable Labels



Silver Fox Legend heatshrink products for cable marking include standard and zero halogen low smoke grade. Silver Fox also offer pre-printed standard heatshrink markers in three sizes to suit all sizes and type of zero halogen cable marking requirements.

Silver Fox Legend zero halogen low smoke grade heatshrink is a flattened, printable single wall matt polyolefin heat-shrinkable tubing for all your identification purposes from single cables to complete cable trees. The Silver Fox heatshrink tubing is flexible, flame-retardant and has a low smoke index. Shrink ratio: 2:1.

Silver Fox Zero Halogen Low Smoke heatshrink is a very flexible, halogen-free and flame retardant single-wall polyolefin within the Silver Fox Heat Shrink tubing range. Silver Fox zero halogen low smoke Thermal Heat Shrink meets the strict safety standards on fire, smoke and non-toxicity for electrical insulation, identification and protection in public transport and building.

Installed using Fox-in-a-Box thermal printing option: Standard / Advanced / Professional.

Printing : Approx. 12,000 x 25mm labels, one roll printing or 24,000 x 25mm, two rolls printing.


Silver Fox Zero Halogen Low Smoke Heat Shrink Tubing - Applications

• Mass Transit Rail Transport
• London Underground
• Rail, Road & Street Tunnels
• Ships & Submarines
• Offshore Platforms
• Airports
• Hospitals
• Public Buildings

Silver Fox Zero Halogen Low Smoke Heat Shrink - Features

• Very high flammability temperature index
• High oxygen index
• Good flame retardency
• Low toxic fume emission
• Very low smoke index
• Free of halogens
• Fully compliant with the London Underground Limited Engineering Standards
• Oxygen Index: >35 (BS EN ISO 4589-2 (1996) Part 2)
• Toxicity Index: <1 (Manual of good practice M1042:A2. 1997)
• General Visibility Distance: >10m (LUL E1042:A6: March 2002)



• Network Rail & London Underground Approved Cable Labels

Silver Fox Legend Heatshrink - Thermal Cable Labels - Part Numbers

Silver Fox Part Number	Cable ODØ exp. (mm)	Cable ODØ rec. (mm)	Roll Length (m)	Pack Quantity	Total Pack Length (m)	Colour Options
LHZ2/R/2.4-1.2T(PF)	2.4	1.2	22	8 Rolls	176
LHZ2/R/3.2-1.6T(PF)	3.2	1.6	22	8 Rolls	176
LHZ2/R/4.8-2.4T(PF)	4.8	2.4	18	6 Rolls	108
LHZ2/R/6.4-3.2T(PF)	6.4	3.2	18	6 Rolls	108
LHZ2/R/9.5-4.8T(PF)	9.5	4.8	18	4 Rolls	72
LHZ2/R/12.7-6.4T(PF)	12.7	6.4	18	4 Rolls	72



Silver Fox Heatshrink Cable Labels - Low Smoke Zero Halogen Cable Labels - Specification

• Durability - Legend LS0H Heat-shrink Labels have been successfully independently tested for High/Low Temperature, H2S Sour Gas Exposure, Salt Mist Spray according to Lloyds Register
• Heat shrink rolls - Uses same printer and ribbon as all other thermal cables and both ends of the cable can be printed at the same time

Silver Fox : Tie-on, Low Smoke Zero Halogen, Heatshrink Tubing, Nonshrink Tubing, 2-Part & Flag Type Cable Labels for power, instrumentation, control, telecoms, data and fibre cable labelling.

Video: Silver Fox Heatshrink Cable Labels - Low Smoke Zero Halogen

Silver Fox Legend Heatshrink Cable Labels - Low Smoke Zero Halogen
