Silver Fox 2-Part Labelling - Laser Cable Labels

Silver Fox 2-Part Cable Labelling System

Cable Labels & Cable Markers

Silver Fox Laser Cable Labels



The Silver Fox Legend 2-part labelling system label fits inside the Silver Fox 2-part labelling system tube which acts as a carrier and also protects the ident.

The tail of the cable label is pulled through the tube then torn or cut after insertion leaving the label in the tube.

Print through any standard laser printer.

Silver Fox 2-Part Labelling System - Heat Shrink Clear Tubing

The Silver Fox heat shrink clear tubing is for use with the 2-part labelling system. The heat shrink tubing acts as both a carrier and protector for the 2-part cable label.

The Silver Fox heat shrink tubing is available in various sizes depending on the diameter of the cable.

Whatever the size, the heat shrink tubing still takes the same label. Additionally, the Silver Fox heat shrink clear tubing and matching labels are available in 3 lengths: 20mm, 30mm and 50mm.

The longer the heat shrink cable label, the more characters that can be printed.

Because of the special design of the 2-part labelling system clear tubing, it is possible to slide the blank tubing onto the cable prior to termination. The label can be applied at any time during and after termination.

Silver Fox 2-Part Labelling - Laser Cable Labels - Part Numbers

Silver Fox Part Number	Laser Cable Label Dim (mm)	Sheet Size	Cable Labels Per Sheet	Pack Quantity	Cable Labels Per Pack	Colour Options
L75/20L(10)	20 x 5	A4	75	10 Sheets	750
L75/20L	20 x 5	A4	75	100 Sheets	7500
L45/30L(10)	30 x 5	A4	45	10 Sheets	450
L45/30L	30 x 5	A4	45	100 Sheets	4500
L38/50L(10)	50 x 5	A4	38	10 Sheets	380
L38/50L	50 x 5	A4	38	100 Sheets	3800

• Network Rail & London Underground Approved Cable Labels



How To Remove Laser Cable Labels

Step 1 – Slide the tubing onto the cable/wire

Step 2 – Pull the printed label through the tubing

Step 3 – Tear/cut off tail

Video: Silver Fox 2-Part Laser Labelling
