Zero Halogen Heat Shrink - LUL Approved

SPS Zero Halogen Heat ShrinkZero Halogen Heat Shrink - LUL Approved



SPS zero halogen medium/thick wall heat shrink tubing complies with London Underground Ltd Standard E1042 : A6 : March 2002 - SPS W3 NH is a flexible high-grade dual-wall flame-retardant, non-halogen, polyolefin heat shrink tubing - specified extensively in the mass-transit and underground rail markets to provide moisture and environmental protection of cables, pipes, harnesses and connectors in all smoke senstitive areas. This includes electrical insulation applications such as surface or underground transport, rail vehicles, tunnels, power plants, hospitals, airports and submarines.

SPS zero halogen heat shrink tubing is specified where smoke generation and toxic gas emissions must be minimised for public safety reasons.


Pictured : Zero Halogen Heat Shrink - LUL Approved

Zero Halogen Heat Shrink - LUL Approved

Zero Halogen Heat Shrink - LUL Approved
Part No Internal Dia Exp (mm) Internal Dia Rec (mm) Wall Thickness Rec (mm) Standard Length
W3 NH 3/1 3 1 0.96 1200mm
W3 NH 6/2 6 2 1.19 1200mm
W3 NH 9/3 9 3 1.27 1200mm
W3 NH 12/4 12 4 1.40 1200mm
W3 NH 19/40 19 6 1.80 1200mm
W3 NH 24/8 24 8 2.50 1200mm
W3 NH 40/13 40 13 2.50 1200mm
W3 NH 50/19 50 19 4.00 550mm
W3 NH 75/25 75 25 3.00 610mm
W3 NH 120/40 120 40 3.00 1200mm

Adobe Zero Halogen Heat Shrink - LUL Approved

UK Time - GMT:

Zero Halogen Heat Shrink - LUL ApprovedZero Halogen Heat Shrink 3mm-1mm - W3 NH 3/1

Zero Halogen Heat Shrink 6mm-2mm - W3 NH 6/2

Zero Halogen Heat Shrink 9mm-3mm - W3 NH 9/3

Zero Halogen Heat Shrink 12mm-4mm - W3 NH 12/4

Zero Halogen Heat Shrink 19mm-6mm - W3 NH 19/6

Zero Halogen Heat Shrink 24mm-8mm - W3 NH 24/8

Zero Halogen Heat Shrink 40mm-13mm - W3 NH 40/13

Zero Halogen Heat Shrink 50mm-19mm - W3 NH 50/19

Zero Halogen Heat Shrink 75mm-25mm - W3 NH 75/25

Zero Halogen Heat Shrink 120mm-40mm - W3 NH 120/40
