Signalling Cable Joint Kits for Type B2 Rail Cables (NR Network Rail PADS)

SPS Signalling Cable JointsHeat Shrink Cable Joints



SPS heat shrink cable joint kits for jointing and splicing type B2 rail signalling cables, 2 core 1.5sqmm-95sqmm - SPS heat shrink joint kits are Network Rail PADS approved.


Application
Heavy duty EPR insulated and heavy duty PCP sheathed single, twin and multicore rail signal cables

Standards
NR/PS/SIG/00005 (formerly RT/E/PS/00005)

Conductor
Class 2 tinned copper conductor to BS EN 60228:2005 (previously BS6360)

Insulation
EPR (Ethylene Propylene Rubber) Type GP4 to BS7655

Cable Sheath
HDPCP (Heavy Duty Polychloroprene) Type RS2 to BS7655

Cable Sheath Colour
Black

Rail Cable Voltage Rating
650/1100V

Pictured : Signalling Cable Joint Kits for Type B2 Rail Cables (NR Network Rail PADS)

Signalling Cable Joint Kits for Type B2 Rail Cables (NR Network Rail PADS)

Signalling Cable Joint Kits for Type B2 Rail Cables - Specification
Part No PADS Joint Description
SPS101 54/37012 2 core 1.5-2.5mm² Type B2 Cable
SPS102 54/15857 2 core 10mm² Type B2 Cable
SPS103 54/15891 2 core 35mm² Type B2 Cable
SPS104 54/15892 2 core 50mm² Type B2 Cable
SPS105 54/15878 2 core 70mm² Type B2 Cable
SPS106 54/15879 2 core 95mm² Type B2 Cable
SPS717 54/37074 Transition 2 core 35mm² Type B2 to 35mm² PILC
SPS748 54/37090 4 core 10mm² Type B2 Cable
