Emtelle PVC Power Duct Systems for Power Cables

Emtelle Power Duct Systems are designed to meet the performance requirements for ducting of low voltage and high voltage underground power cables - Emtelle underground power cable ducting meets industry standard EATS 12-24 revision 2 :

Class 1 Solid Wall PVC-U Cable Duct System
450N compression force up to 75 Degrees C

Class 2 Solid Wall PVC-U Cable Duct Systems
450N compression force up to 50 Degrees C

Class 3 Coiled SOlid Wall HDPE Cable Duct Systems for service cables

Emtelle Power Duct Systems are specified and installed by all major Distribution Network Operators including UK Power Networks, EDF, NEDL/YEDL, United Utilities, Scottish Power, Scottish & Southern Energy, Western Power, NIE and ESB Ireland.

United Utilities Cable Ducting - 38mm OD (32mm ID), 125mm OD (117mm ID), 160mm OD (150mm ID) and Shallow Depth Burial Duct (Red 160mm HDPE 6m Duct).

Scottish Power LV Cable Ducting - Electric Cable Duct HDPE (38mm OD, 32mm ID) plus 50mm, 110mm, 160mm Duct.


Emtelle PVC Power Duct Systems for Power Cables

OD SIZE nominal (mm)	I>D Nominal/ (mm)	WALL THICKNESS nominal/ (mm)	EN 50086 2-4 Compression Strength Classification in Newtons	EN 50086 2-4 Impact Strength Classification in Joules
42	39	1.5	250
42	38	1.8	450	15
42	38	2.1	750
50	47	1.65	250
50	46	2	450	15
50	45	2.4	750
54	51	1.75	250
54	50	2.1	450	15
54	49	2.5	750
88.9	84	2.4	250
88.9	83	2.95	450	20
88.9	82	3.5	750
96.5	91	2.55	250
96.5	90	3.1	450	28
96.5	89	3.7	750
105	100	2.7	250
105	98	3.3	450	28
105	97	3.9	750
110	104	2.8	250
110	103	3.37	450	28
110	102	4	750
125	119	3	250
125	118	3.7	450	28
125	116	4.35	750
140	133	3.3	250
140	132	4	450	40
140	131	4.7	750
160	153	3.6	250
160	151	4.35	450	40
160	150	5.13	750
200	192	4.15	250
200	190	5.05	450	40
200	188	6.05	750



ENA 12-24 Issue 2 Feb 2008 Technical Specification for Plastic Cable Duct for Underground Cable
