Pfaff Silberblau rack and pinnion cable drum jacks are designed for heavy duty cable drum lifting applications - cable drum lifting capacity 1,500 to 10,000kgs.

Pictured: Pfaff Silberblau Rack And Pinnion Cable Drum Jacks

The cable laying drum jacks enable very large diameter cable drums to be unreeled quickly and safely.

Pfaff Silberblau cable drum lifting jacks feature wheel assemblies allowing easy movement of the cable jacks between cable laying pulls.

5 and 10 tonne cable drum jacks are supplied with fixed head and adjustable claw - large drum lifting jack base ensures stability and safe cable laying and cable pulling.

Cable Drum Jacks (Pfaff Silberblau) - Rack & Pinnion - Product Specification

Part Number	0024015	0025011	0026018
Capacity On Head (T)	1.5	5.0	10.0
Capacity On Claw (T)	1.0	2.5	5.0
Lifting Height (mm)	265	410	500
Number of Additional Claws	2*	1**	1**
Weight Without Rollers (kg)	30	69	105
Weight With Rollers (kg)	32	73	110
Position of Claw 1	200	341	520
Position of Claw 2	380	453	632
Position of Claw 3	558	565	744
Position of Claw 4	-	677	856
Position of Claw 5	-	789	968
* 1.5 with head and 2 fixed claws
** Claw with 5 adjustable positions
