26 Way Earth Bars EBC226

Earth Bars with Twin Disconnecting Link

AN Wallis

EBC226

26 Way Earth Bars with Twin Disconnecting Links

Number of Terminations 26

Length 1720mm

Width 90mm

Height 60mm

The EBC226 earth bar is manufactured from copper with 26 way brass M10 stud assemblies - all copper earth bars are made from 50mm x 6mm hard drawn copper bar. Earth bars are available with single or twin disconnecting links allowing the copper earth bars to be isolated for electrical earthing testing.

• Dimensions: 1720mm x 90mm x 60mm (L x W x H)
• Number of Terminations & Ways: 26 with Twin Link
• Unit Weight: 11.60kg
• Material: Copper to BS EN 13601 (formerly BS 1432)

Pictured: AN Wallis 26 Way Earth Bars EBC226

No of Ways | Cable Terminations	Earth Bar Type	Length	Width	Height	AN Wallis Order Code
26 Way	Standard	1550mm	90mm	60mm	EBC016
26 Way	Single Way	1635mm	90mm	60mm	EBC116
26 Way	Twin Links	1720mm	90mm	60mm	EBC216

26 Way Wallis Earth Bars - 1720x90x60mm - Wallis Earth Bar EBC 226
