24 Way Earth Bars EBC224

Earth Bars with Twin Disconnecting Link

AN Wallis

EBC224

24 Way Earth Bars with Twin Disconnecting Links

Number of Terminations 24

Length 1570mm

Width 90mm

Height 60mm

The EBC224 earth bar is manufactured from copper with 24 way brass M10 stud assemblies - all copper earth bars are made from 50mm x 6mm hard drawn copper bar. Earth bars are available with single or twin disconnecting links allowing the copper earth bars to be isolated for electrical earthing testing.

• Dimensions: 1570mm x 90mm x 60mm (L x W x H)
• Number of Terminations & Ways: 24 with Twin Link
• Unit Weight: 10.70kg
• Material: Copper to BS EN 13601 (formerly BS 1432)

Pictured: AN Wallis 24 Way Earth Bars EBC224

No of Ways | Cable Terminations	Earth Bar Type	Length	Width	Height	AN Wallis Order Code
24 Way	Standard	1400mm	90mm	60mm	EBC024
24 Way	Single Way	1485mm	90mm	60mm	EBC124
24 Way	Twin Links	1570mm	90mm	60mm	EBC224
