16 Way Earth Bars EBC216

Earth Bars with Twin Disconnecting Link

AN Wallis

EBC216

16 Way Earth Bars with Twin Disconnecting Links

Number of Terminations 16

Length 1120mm

Width 90mm

Height 60mm

The EBC216 earth bar is manufactured from copper with 16 way brass M10 stud assemblies - all copper earth bars are made from 50mm x 6mm hard drawn copper bar. Earth bars are available with single or twin disconnecting links allowing the copper earth bars to be isolated for electrical earthing testing.

• Dimensions: 1120mm x 90mm x 60mm (L x W x H)
• Number of Terminations & Ways: 16 with Twin Link
• Unit Weight: 7.10kg
• Material: Copper to BS EN 13601 (formerly BS 1432)



Pictured: AN Wallis 16 Way Earth Bars EBC216

No of Ways | Cable Terminations	Earth Bar Type	Length	Width	Height	AN Wallis Order Code
16 Way	Standard	950mm	90mm	60mm	EBC016
16 Way	Single Way	1035mm	90mm	60mm	EBC116
16 Way	Twin Links	1120mm	90mm	60mm	EBC216



16 Way Wallis Earth Bars - 1120x90x60mm - Wallis Earth Bar EBC 216
