Earth Rods - Copperbond

Earth Rods - Copperbond

Material: Copper to BS EN 13601

AN Wallis Earthing & Lightning Protection Distributors



Copperbond earth rods offer installers the most economical method of achieving a low earth resistance - each earth rod has a high tensile strength, low carbon steel core.

99.95% pure copper is applied electrolytically forming a metallurgical bond between the steel core and the copper. This combination makes the copper earth rod ideal for deep driving whilst also provides lasting resistance to corrosion in aggressive soil and ground conditions.

The standard copper earth rod thickness is 0.25mm.

Copperbond earth rods are available with 1/2″, 5/8″ and 3/4″ threads – solid copper earth rods also available.

Pictured: AN Wallis Copperbond Earth Rods (Copper manufactured to BS EN 13601 standards)

99.95% pure copper is applied electrolytically forming a metallurgical bond between the steel core and the copper.

The standard copper earth rod thickness is 0.25mm. Copperbond earth rods are available with 1/2", 5/8" and 3/4" threads.

The table enables the selection of copperbond threaded earth rods when specifying copper conductors for earthing and lightning protection systems.

AN Wallis Copperbond Earth Rods - Product Range

Threaded
Part Number	Nominal Size	Length	Thread Size (UNC-2A)	Shank (D)	Length 1	Unit Weight	Pack Quantity
ERB 412	1/2"	1200mm	9/16"	12.7mm	30mm	1.18kg	5
ERB 415	1/2"	1500mm	9/16"	12.7mm	30mm	1.55kg	5
ERB 418	1/2"	1800mm	9/16"	12.7mm	30mm	1.76kg	5
ERB 424	1/2"	2400mm	9/16"	12.7mm	30mm	2.36kg	5
ERB 112	5/8"	1200mm	5/8"	14.2mm	30mm	1.53kg	5
ERB 115	5/8"	1500mm	5/8"	14.2mm	30mm	1.88kg	5
ERB 118	5/8"	1800mm	5/8"	14.2mm	30mm	2.29kg	5
ERB 124	5/8"	2400mm	5/8"	14.2mm	30mm	3.00kg	5
ERB 130	5/8"	3000mm	5/8"	14.2mm	30mm	3.79kg	5
ERB 212	3/4"	1200mm	3/4"	17.2mm	35mm	2.19kg	5
ERB 215	3/4"	1500mm	3/4"	17.2mm	35mm	2.73kg	5
ERB 218	3/4"	1800mm	3/4"	17.2mm	35mm	3.27kg	5
ERB 224	3/4"	2400mm	3/4"	17.2mm	35mm	4.35kg	5
ERB 230	3/4"	3000mm	3/4"	17.2mm	35mm	5.44kg	5
Unthreaded
Part Number	Nominal Size	Length		Shank (D)		Unit Weight	Pack Quantity
ERB 012	3/8"	1200mm		9.5mm		0.62kg	5



Video : Copperbond Earth Rods - AN Wallis ERB012 Internally Threaded Copper Earth Rods

Copper Earth Rods - AN Wallis Copperbond Earth Rods
