Cembre TC120 Cable Cutting Head for SWA Armoured Cables

Cembre Cable Cutters & Cutting Tools

UK Distributor

Cembre TC120 - The Armoured Cable Cutting Tool from Cembre



Cembre TC120 is the essential cable cutting tool for the LV-HV cable jointer and electrical contractor - the TC120 hydraulic cable cutting head is suitable to cut copper, aluminium and telecommunications cables including steel wire armoured (SWA) and lead sheaths up to 120mm diameter.

Cembre TC120 cable cutting head has a cutting capability up to 4 core 400sqmm XLPE SWA (steel wire armoured) cables - the TC120 tool is the industry standard for the specialist LV-HV jointer and cable contractor.

Cembre TC120 cable cutter head features the two-speed cutting action : quick blade advance to cable, slower blade cut through cable.

Cembre TC120 couples to a variety of 700 bar hydraulic pump units, including Cembre PO7000 unit.

Cembre TC120 is used by cable contractors for cutting BS5467 and BS6724 armoured LV power cables and medium voltage BS6622 and BS7870 11kV-33kV power cables - check with T&D for cable cutting advice.

See for yourself, request a site demonstration for the Cembre TC120.

Video - Cembre TC120 Cable Cutting Tool

Cembre TC120 Cable Cutting Tool - Up to 120mm Dia Cables

Cembe TC120 Cable Cutting Tool - Technical Drawing

Cembre PO7000 Foot Pump for Use with Cembre TC120 Cutting Head
