SM580 50kV Tested Switchgear & Switchboard Matting - 1000v Working Voltage (VDE0303)

Insulating Matting

VDE0303 Electrical Safety Rubber Matting

Tested Voltage 50kV

Working Voltage 1000v

SM580 Electro Safe

Fully tested general-purpose electrical safety rubber matting and stamped on the reverse every 100cm. High quality, rubber compound, electrical safety, switchgear matting made to exacting standards and fully tested to 50kV.

50kV tested and certified electrical switchboard/switchgear matting is 6.0mm thick and provides safe working voltage to 1000V.

50kV Standard Matting Stock Sizes (4.5mm Thick)

• 50kV Rubber Electrical Switchboard Matting 0.91m x 10m - ex stock
• 50kV Rubber Electrical Switchboard Matting 1m x 10m - ex stock
• 50kV Rubber Electrical Switchboard Matting 1.2m x 10m - ex stock

Fine Ribbed Rubber Matting to 50,000v - Grey VDE0303 Grade

• Working Voltage Test 1000 Volts

50kV Insulating Matting

Matting Thickness	Roll Size 0.91m x 1m	Roll Size 10m x 1m	Roll Size  10m x 1.2m	Weight/sqM kgs Approx	Tested Voltage	Working Voltage
4.5mm	Ex Stock	Ex Stock	Ex Stock	5.5	50kV	1000V



SM580 Electrical Matting Specification

• Colour : Black
• Hardness : 65 shore A
• Density (SG) : 1.3
• Tensile Strength : 5.0Mpa
• Elongation : 250%
• Temperature Range : -20/+70 Degrees Celsius
• Abrasion Resistance : 180mm3

1000V Working / 50kV Tested Voltage - Insulating Matting Details

• Application: Insulating Matting for Substations/Switchgear/Electrical Safety
• Thickness: 4.5mm
• Resistance to: Please call T&D
• Colour: Grey
• Insert Requirements: No
• Solid: Yes
• Drainage Holes: No

T&D distribute LV, MV & HV insulating matting and electrical safety equipment for use in substations, switchrooms, overhead line and underground cable installations including 6.6kV, 11kV, 33kV and 66kV-132kV voltages.

Switchboard/Gear Matting (VDE0303) - Electrical Safety Rubber Matting- 50kV Tested, 1000v Working
