CATU Single Pole Phase Comparators

Phase Comparators to IEC 61481-1 (CE Marked)



CATU single pole (unipolar) phase comparator device for indoor and outdoor use on medium or high voltage cables, overhead lines and switchgear - phase comparators suitable for 50 Hz and 60 Hz networks.

Phase comparator devices check either live cable conductor in a medium or high voltage electricity supply network for "in-phase" or "out-of-phase" condition - this includes 3.3kV, 6.6kV, 11kV, 15kV, 25kV and 33kV cable networks.

When applied to the medium or high voltage electricity sources under testing the hand held CATU phase comparators provide clear visual indication of an "out of phase" condition.

• GREEN LED - Phasing Indication
• RED LED - Non-Phasing Indication
• ORANGE LED - Memorized Phase Status Voltage Function

CATU Single Pole Phase Comparators

Part Ref	Operating Voltage	Type LF 22	Aerial Total Length	Weight
CATU CL-06/18	6-18kV	9V	0.55m	850g
CATU CL-10/30	10-30kV	9V	0.90m	900g
CATU CL-10/30-1	10-30kV	9V	1.15m	950g
CATU CL-12/36	12-36kV	9V	0.90m	900g



Pictured: Single Pole Phase Comparator By CATU
