XLPE Insulation Stripping Tools for HV Triplex Cables

Boddingtons ElectricalCable Jointing Tools

Cable Insulation Stripping Tools for 11kV Triplex Cables







XLPE Insulation Stripping Tools are ideal for removing XLPE insulation from high voltage (HV) 11kV triplex cables - this includes 95sqmm, 185sqmm and 300sqmm high voltage 11kV triplex cables to BS7870 Part 4.



Pictured: XLPE Insulation Stripping Tools for HV Triplex Cables

XLPE Insulation Stripping Tools for HV Triplex Cables



Triplex Insulation Cable Stripping Tools 11kV - Benefits

  • The triplex cable stripping tool comprises of a T- handle (with a built in length adjustment mechanism) and various interchangeable triplex stripping inserts for different voltages (11kV and 20kV) and cross sections (95sqmm, 185sqmm, 300sqmm).



  • The connection between the T- handle and the cable stripping tool insert is by means of a bayonet cap, therefore there is no need for additional cable jointers tooling.



  • Each triplex stripping insert contains a stripping blade designed and positioned to strip easily and precisely the EPR or XLPE and the semi-conductive layer in contact with the high voltage cable core, the insulation is stripped without damaging the cable core.



  • Once the cable stripping operation is complete, the surface is uniform and the length cut away is corresponding to the chosen stripping length on the scale previously set.





Adobe Jointers Tools - XLPE Insulation Stripping Tools for HV Triplex Cables 95sqmm, 185sqmm 300sqmm
