Cable Sheath Cutting Pliers

Cable Jointing Tools

Cable Sheath Cutting Pliers

Boddingtons Electrical





Cable Sheath Cutting Pliers are designed for cable jointers to strip outer sheaths with thicknesses from 0.5mm to 5mm of low voltage (LV), medium voltage (MV) and high voltage (HV) cables with diameters from 16mm to 54mm. Cable sheath cutting pliers can be used by LV jointers on live cables up to 1000VAC and 1500V DC.



Pictured: Cable Sheath Cutting Pliers

Cable Sheath Cutting Pliers - Benefits

• For cable jointers cutting and removing low voltage cable outersheaths



• Cable sheath cutting pliers developed for safe and easy circumferential and longitudinal sheath cutting



• The longitudinal section can be cut without risk of injury to the cable jointer due to the ratchet system.



• Colour coded, easy exchangeable plastic rings limit the sheath cutting depth in 0.5mm steps from 0.5mm up to 5mm.



• Fully insulated cable sheath cutting pliers to EN60900 - 1000V max working.



• Jointing tools are supplied in protective plastic case with foam padding.



• Jointers tool sets include cutting pliers, cutting wheels, plastic rings, ratchet handle and case.



• The sheath stripping pliers guarantees a smooth finish without irregularities after cable shaving and further guarantees a high quality chamfered edge ready for cable jointing.



• Cable stripping pliers can be used on cables 10mm to 52mm diameter



• The depth of sheath cut is adjustable from 0 to 1.5mm in steps of 0.1mm without the need of additional tools and can also be limited or locked



• Sheath cutting pliers are compliant to EN 10020
