Earth Inspection Housing Pits (Heavy Duty Plastic)

AN Wallis heavy duty earth pits are designed, shaped and sized to fit easily into brick paved walkways. The lip of the base makes a flush fit with standard sized bricks making the earth pit blend in without the need for a cement surround.

The housing will withstand loads of up to 6,000 kilograms and is suitable for most commercial and industrial applications. The lid locks into the base and can be opened with a standard flat screwdriver. The base has three built-in slots for locating copper earth bars.

Pictured: Wallis Heavy Duty Plastic Earth Inspection Housing Pits

Wallis Earth Inspection Housing Pits (Heavy Duty Plastic) - Product Range

Part Number	Lid Colour	Dimensions	Lid Dimensions	Unit Weight	Pack Quantity
EPP 001 W	Black	306mm x 306mm x 216mm	260mm x 260mm x 55mm	3kg	1
EPP 002 W	Grey	306mm x 306mm x 216mm	260mm x 260mm x 55mm	3kg	1



Earth Inspection Housing Pits (Light Duty Plastic)

AN Wallis light duty earth inspection pits have a maximum safe working load of 2,000 kilograms and are UV stabilised against degradation by sunlight and non-brittle to prevent cold weather damage. The unique, detachable easy-locking lid ensures security of earthing equipment as the locking mechanism can only be operated by the special key provided with the housing.

The base has built-in slots for locating copper earth bars. Its lightweight feature allows easy handling, storage and transportation. The termination depth is increased 100% by simply locking two units together allowing deeper earth electrode connections to be made.

Pictured: Wallis Light Duty Plastic Earth Inspection Housing Pits

Wallis Earth Inspection Housing Pits (Light Duty Plastic) - Product Range

Part Number	Lid Colour	Dimensions	Lid Dimensions	Unit Weight	Pack Quantity
ERH 20	Black	260mm x 260mm x 230mm	200mm x 200mm	1.5kg	1
ERH 21	Grey	260mm x 260mm x 230mm	200mm x 200mm	1.5kg	1



Earth Inspection Housing Pits (Concrete)

AN Wallis concrete earth inspection housing is load rated to 4,000 kilograms and is suitable for most industrial applications. The earth pit can have an internal earth bar fitted diagonally across in slots provided in the base.

Pictured: Wallis Concrete Earth Inspection Housing Pits ERH 01W

Wallis Earth Inspection Housing Pits (Concrete) - Product Range

Part Number	Lid Type	Dimensions	Unit Weight	Pack Quantity
ERH 01W	Non Trip Plain Lid	315mm x 315mm x 170mm	24kg	1
ERH 02W	Central Lifting Eye	315mm x 315mm x 170mm	24kg	1
