Bostrig MHV3-15BS IEC 8.7/15 kV

Three Conductor Power (Type N Jacket & Sheath) 15 kV (IEC 8.7/15 kV)

Shielded 100% Level Armoured and Sheathed

Prysmian Draka Offshore Drilling Cables

Prysmian

Offshore Marine Cables - NEK 606/BFOU/RFOU/BU/RU topside cable including halogen-free, fire resistant and mud resistant LV, MV & HV power cables (3.3kV, 6.6kV and 11kV).



Prysmian Draka Cables

Bostrig MHV3-15BS IEC 8.7/15 kV Applications

Prysmian Draka Bostrig MHV3-15BS IEC 8.7/15 kV three conductor 15,000 volt shielded cables are suitable for use in commercial marine applications, MODU’s, and platforms where flame retardant cables having excellent physical and electrical properties are required. The Bostrig MHV3-15BS IEC 8.7/15 kV cables have excellent resistance to oils, abrasion, petrochemical fluids, moisture, and sunlight. When required these cables can be supplied without the sheath over the armour. Bostrig MHV3-15BS IEC 8.7/15 kV cables are also available with either a fully insulated grounding conductor or an un-insulated grounding conductor evenly distributed in the interstices.



Prysmian Draka Cables

Bostrig MHV3-15BS IEC 8.7/15 kV Approvals

Meets applicable test requirements in IEC 60502, IEC 60092-354, IEEE 45-1998 & 1993 (draft), ICEA S-68-516, UL 1072, J-128

Flame test in IEC 60332-3, cat A, A/F.



Prysmian Draka Cables

Bostrig MHV3-15BS IEC 8.7/15 kV Construction

  • Conductor - Soft annealed tinned copper
  • Conductor Shield - Semi-conducting tape with extruded thermosetting semi-conducting EPR
  • Insulation - Extruded thermosetting EPR, 90°C-Type E
  • Insulation Shield - Extruded thermosetting semi-conducting XLPO
  • Metallic Braid Shield - Tinned copper braided shield, 85% minimum coverage
  • Jacket - A jacket of flame retardant, heavy duty arctic Neoprene is applied over the metallic braid shield
  • Armour - Braized Bronze
