Control Panels - Stainless Steel Hazardous Area ATEX - Walsall Panel XLCP9 - 762x508x150mm

Stainless Steel Control Panels - Walsall XLCP EEx edm

Walsall Panel XLCP9 - 762x508x150mm

Control Panels - Stainless Steel Hazardous Area ATEX - Walsall Panel XLCP9 - Features

• Zone 1, 2, 21, 22 • II 2 GD
• Certification Ex edm IIC T5/6 Gb Ex tb IIIC T130/160 °C Db
• Ambient temperature range -50 °C to +50°C
• IP66 to EN60529:1992
• Electropolished 1.5mm(FXLCP3) or 2mm(FXLCP5, 6 & 9) 316L Stainless Steel or powder coated Mild Steel box
•  0 - 4 Electropolished 3mm 316L Stainless Steel or powder coated Mild Steel gland plates
• FXLCP9 - 762mm x 508mm x150mm
• 4 External mounting feet
• Padlockable hasp as an option
• Return flange rain channel
• Concealed hinges
