Cast Iron Control Panels - Walsall ASMCP/CI EEx d Control Panels

Walsall - Hazardous Area ATEX Distribution Boards & Control Panels Zone 1 & Zone 2

Explosion Proof & Flameproof Control Panels

Control panels made from cast iron suitable for hazardous area zones 1, 2, 21 and 22 with ATEX certification – the Walsall ASMCP/CI Control Panel range :

Cast Iron Control Panels - Walsall ASMCP/CI EEx d Control Panels - Features

• Zone 1, 2, 21, 22 • II 2 GD
• Certification Ex d IIB T6 Gb Ex tb IIIC T76°C Db
• Ambient temperature range -20 °C to +50°C
• IP66 to EN60529:1992
• Available in cast iron, cast aluminium and cast stainless steel
• Available sizes - ASMCP150/CI/AL/SS - 335mm x 310mm x 200mm ASMCP170/CI/AL/SS - 560mm x 560mm x 245mm • 4 external mounting holes
